使用产品：idesktop10i leaflet iserve10i 操作系统：win10 x64
数据类型： 文件型
问题详细描述：在idexktop中，通过一个数据集创建了一个三维柱状专题统计图，把工作空间发布以后，通过发布的地图url显示在地图上，但是并未展示柱状图，同一地图上的其他专题图可以正常显示
问题重现步骤：
1.在idesktop上制作专题图
2.发布：
3.发布后的效果
4.前端代码获取专题图
// 获取专题图层
getThemeLayer(data) {
this.legrndSrc = data.legendURl;
this.clearThemeLayer();
if (data.id == 8 || data.id == 9 || data.id == 12) {
this.showDialog = true;
this.getCensusResults(data);
} else {
let url =
this.$gisJoint.URL_MAP_IP +
"/iserver/services/map-tgMap/rest/maps/" +
data.label +
"@自然灾害普查";
this.themeLayer = L.supermap.tiledMapLayer(url, {
// noWrap: true,
// redirect:true,
// isLayer: true,
// // overlapDisplayed:true,
prjCoordSys: { epsgCode: 3857 },
// minZoom: 1, // 设置地图的最小缩放级别
// maxZoom: 18,
});
this.themeLayer.setZIndex(20);
this.themeLayer.addTo(this.map);
if (data.id == 7) {
this.getBar(url);
}
}
},
5.结果：只有设置颜色块的单值专题图层 没有柱状图
6.尝试用前端代码的方式从数据集中获取数据生成也失败，代码如下：
// 柱状图
getBar(url) {
let that = this;
let themeService = L.supermap.themeService(url);
let themeGraph = new SuperMap.ThemeGraph({
items: [
new SuperMap.ThemeGraphItem({
caption: "O_gxzgnsvzz",
graphExpression: "O_gxzgnsvzz",
uniformStyle: new SuperMap.ServerStyle({
fillForeColor: new SuperMap.ServerColor(92,73,234),
lineWidth: 0.1
})
}),
new SuperMap.ThemeGraphItem({
caption: "各乡镇国内生产总值",
graphExpression: "O_gxzgnsvzz",
uniformStyle: new SuperMap.ServerStyle({
fillForeColor: new SuperMap.ServerColor(92, 1, 255),
lineWidth: 0.5,
lineColor: new SuperMap.ServerColor(92, 1, 255)
})
}),
],
barWidth: 1,
graphSizeFixed:true,
graphType: SuperMap.ThemeGraphType.BAR3D,
graduatedMode: SuperMap.GraduatedMode.CONSTANT,
graphAxes: new SuperMap.ThemeGraphAxes({
axesDisplayed: true,
}),
graphSize: new SuperMap.ThemeGraphSize({
maxGraphSize: 1,
minGraphSize: 0.35,
}),
graphText: new SuperMap.ThemeGraphText({
graphTextDisplayed: true,
graphTextFormat: SuperMap.ThemeGraphTextFormat.VALUE,
graphTextStyle: new SuperMap.ServerTextStyle({
sizeFixed: true,
fontHeight: 9,
fontWidth: 5,
}),
}),
});
let themeParameters = new SuperMap.ThemeParameters({
themes: [themeGraph],
dataSourceNames: ["自然灾害普查"],
datasetNames: ["行政边界源"],
});
console.log(
"themeParametersthemeParametersthemeParameters",
themeParameters
);
themeService.getThemeInfo(themeParameters, function (serviceResult) {
var result = serviceResult.result;
if (result && result.newResourceID) {
let themeLayer = L.supermap.tiledMapLayer(url, {
noWrap: true,
cacheEnabled: false,
transparent: true,
layersID: result.newResourceID,
prjCoordSys: { epsgCode: 3857 },
});
themeLayer.setZIndex(30);
themeLayer.addTo(that.map);
console.log(that.map);
}
});
},
